Item 759AH
Previous Item | Next Item
CB29AH Connector Board
High Voltage Transition System for Wire Harness Assembly Boards
64 Screw Terminals with 0.200" (5mm) Spacing
Configuration
This board has the same functionality as the CB29A stackable board. The only difference is the voltage rating and the orientation of the terminal blocks.
2 Set of two boards.
Voltage Rating
Rated for operation up to 2100Vdc and 1200Vac when used with Item 864 Ampmodu dscrete-wire extension cable (not illustrated, not included).
Can be certified for operation at the maximum rated voltage for a service fee (Item 626).
