Power: Low Voltage Testers
CableEye low voltage testers require a wall-mounted power module as follows:
9Vdc Unregulated at 300mA (max), 3W
M3U Series, M4
18Vdc Unregulated at 500mA (max), 9W - for control module and expansion units
The output connector is a standard 2.5mm circular DC power jack. Any foreign-style power module that provides this output will be adequate. At your preference, we will either ship the USA-style power module, ship no power module, or provide the proper power module for your country and advise you of any additional cost.
The same warranty that applies to US buyers also applies to foreign purchasers. You receive a one-year warranty on parts and labor for hardware support (excluding shipping), and will receive software updates & upgrades for one year at no charge. We have found the hardware to be extremely reliable, so it is unlikely that the test fixture will pose any problems under normal use. Additional benefits are included with the warranty. Click the link for details.
Click here for on-line catalog.
Please contact your local authorized distributor for local prices.
If there is no local distributor for your region, and you contact us directly, note that quoted prices are USA only and subject to exchange rates, freight and import costs.
CableEye is a highly versatile, expandable and upgradable diagnostic and Pass/Fail check Cable and Harness Test System that’s PC-based. It’s used for assembly, prototyping, production, and QC of standard or custom wire cables and harnesses The entire suite of products is powered by the same easy-to-use operating software and, with the help of its signature easy-to-interpret color-coded graphics, instantly identifies not only when there is a fault, but what type of fault and where. There are several models:
Low Voltage: M2U-basic, M2U
For diagnostic and Pass/Fail Testing - Find, display, log, & document: continuity (opens, shorts, miswires, intermittent connections).
Low Voltage: M3U, M3UH
For all of the above plus resistance (contact, isolation, embedded), and diodes (orientation, forward voltage, reverse breakdown).
Low Voltage: M4
For all of the above plus precision resistance (4-wire), and capacitance (twist wire relationship, length of cable, length to break, capacitors).
Low Voltage and High Voltage: HVX, HVX-21
For all as described for M3U, M3UH plus 4-Wire Kelvin Measurement and HiPot (dielectric withstand voltage and insulation resistance). Capacitance measurement (twist wire relationship, length of cable, length to break, capacitors) is an option.
